LEXIS 3000

Description

Lexis 3000

Tank Capacity: 3,000 L main tank (actual ~3,150 L) plus 320 L rinse tank.
Boom Range: Steel or aluminum booms from 18 m to 24 m (up to 28 m depending on configuration).
Pump Options: Piston-diaphragm (170–280 L/min) or centrifugal, pressure up to 7 bar.
Transport Dimensions: Length ~4.05 m, width ~2.23 m, height 3.10–3.50 m depending on boom size.
Simplified Operation: Manuset/Diluset valve system reduces operation steps by up to 50%.
Easy Maintenance: Centralized service area and easy filter access for quick servicing.

Features

Slope Control: Hydraulic hillside/slope compensation option..
Unladen Weight: ~2,057 kg (example for 24 m version).
Track Gauge / Tires: Standard 9.5 × 48 tires, adjustable track width 1.50–2.25 m.
Compact Design: Short hitch-to-axle length for easy maneuverability and stability in transport.
Precision Application: Optional GPS section control via VISIOREB or REB terminals for accurate spraying and automatic shutoff at headlands.
