AXIS 40.2 H-EMC

AXIS 40.2 H-EMC

• Type: Mounted twin-disc fertilizer spreader with Hydraulic drive (H) and Electronic Mass Control (EMC).
• Working Width: Adjustable between 12–42 m.

• Drive & Flow: Hydraulic pump from tractor; consistent spread regardless of PTO speed.
• Application Rate: Up to ~500 kg/min (~1,100 lb/min) with less than 1% deviation thanks to EMC per-disc metering.
• Other Systems: CDA distribution adjustment for quick working width changes; ISOBUS and GPS section control compatible.
• EMC Technology: Continuously monitors and adjusts fertilizer flow per disc second-by-second for extreme accuracy.

1. PTO Power: ~85 hp (63 kW).
2. Empty Weight: ~545–600 kg (1,200–1,325 lb).
3. Hydraulic Requirement: Minimum ~12 gal/min at ~2,610 psi.
4. Base: ~1,400 LWith extensions: Up to ~3,200 L (max payload ~3,198 kg).
5. Hydraulic Disc Drive (H): Independent of PTO speed, allowing fuel-efficient operation and stable spread patterns.
