663R

663R Frontloader

• Engine (tractor): 4.5 L PowerTech™ 4‑cylinder, ~155–195 hp depending on model
• Transmission: PowrQuad™, AutoQuad™ Plus, or IVT (varies by tractor series)
• PTO: Rear PTO 540/540E/1000 rpm (electro‑hydraulic)
• Hydraulics/Hitch: Load‑sensing system, ~114 L/min (optionally higher); Cat II/III hitch with rear lift capacity ~8,500 kg

• Weight/Fuel: Combined loader + tractor around ~6,800 kg; fuel tank ~240–260 L (Tier‑4 includes DEF)

1. Pivot lift capacity: ~4,550 kg.
2. Full-height capacity: ~2,563 kg at ~4.52 m lift height.
3. Automatic Implement Latch (AIL) — swaps buckets or forks in under 3 seconds.
4. Multiple leveling options — Mechanical (MSL) or Non-Self-Levelling (NSL) variants available.
5. Curved boom and slim profile — excellent visibility and tighter steering clearance.
